Stage rental LED display price plan

With the technological innovation and development of LED displays, LED rental screens are frequently used in large-scale activities such as stage backgrounds, bar entertainment, wedding ceremonies, music theaters, conferences, etc., and the stability of LED rental screens plays a vital role in the whole process, especially the rental series of performance live activities.

The main application is the stage background, and its extremely high requirements for the creation of virtual space effects and color use make the LED display system the core element of stage creativity and is widely used.

Large concerts, television stages, performance venues, stage LED displays are widely used. If you want to understand the price of stage LED display, you need to understand the price of LED display composition of various parts, the following is the stage LED display program, for your reference:

I、Overview of the application scheme

The compact LED rental display made with a patented die-cast aluminum cabinet greatly improves the appearance and function of the panel. The LED cabinet is light and thin, with high splicing accuracy, and is extremely convenient for disassembly, assembly and maintenance. It also has good safety, efficiency and easy installation.

II、 The stage rental LED display function

1. Live broadcast, super large and clear live broadcast screen, breaking the limitation of seats, making it easier to watch the performance from a distance.

2. Wonderful close-ups, slow-motion playback, and random changes of various stage backgrounds bring the artistic conception of the performance to the extreme.

3. The perfect combination of realistic graphics and shocking music creates a dreamlike stage background.

III、 Features of stage rental LED display:

1. High-definition perfect picture quality, new visual experience, and a new generation of technology；

2. High refresh rate above 1920HZ, 14bit high gray scale, realistic picture, meet the high visual quality requirements of commercial use；

3. Automatic brightness adjustment function, automatically adjust the brightness of the display according to the changes of indoor and outdoor light, energy saving and environmental protection；

4. High-precision machining, die-casting aluminum box with CNC finishing, size tolerance less than 0.2mm, seamless splicing of LED box, standardized design, can be assembled arbitrarily, high-grade and beautiful;

5. Specific models, support staggered splicing, to achieve more shapes. The side of the box is designed with a radian scale and a side lock, which can be spliced with any radian from -15 degrees to 15 degrees；

6. Easy to disassemble and assemble, saving labor costs;

7. Zero noise, fanless design, energy saving more than 30% compared with traditional screens, providing a quiet working environment；

8. Professional audio and video processing system, support the processing of a variety of signals, ensure the playback of high-fidelity image signals, and realize live broadcasting;

9. Equipped with an aviation box, which is convenient for the storage and transportation of the LED rental box, and protects the screen;

10. Outdoor models up to IP65 protection level, waterproof and dustproof, suitable for outdoor use;

11. According to customer requirements and on-site environment, tailor-made the most suitable LED display solution.

IV、the commonly used LED rental large screen models on the stage are:

P3, P3.91, P4, P4.81, P5, the smaller the number, the higher the definition; Conventional P3, P4, P5 models, P3 box size 576mm*576mm; P4 box size: 512mm*512mm or 768mm*768mm; P5 box size: 480mm*480mm or 640mm*640mm; In order to facilitate the calculation of the size of the stage screen, P3.91 and P4.81 full-color models are specially launched, and the box size is made to 500mm*500mm or 500mm*1000mm.

The main components of full-color rental LED display are: LED light-emitting chips, packaging processes, IC driver chips, power supplies, control cards, PCB circuit boards, module kits, and masks.

V、Instructions for purchasing LED displays:

1. Whether it is a customized indoor or outdoor LED display, the first thing to do is to determine the size of the screen: generally speaking, customers only need to provide the preliminary length and height dimensions of the LED display, and the business personnel of the LED display manufacturer can calculate the most suitable screen size and the size of the outer side: for example, the general customer says that I need to make a screen with a length of 10*6 meters high, then the business personnel will give a specific plan and price according to the size required by the customer.

2. After determining the size of the LED display, you can choose the specific model: the selection of indoor full-color LED display specifications should not only focus on high density and good definition, nor is it the smaller the better, and it is best to fit a specific environment. Therefore, it is best to comprehensively consider the actual display needs of the LED display, and it is recommended to comprehensively consider the display production area, installation location, playback content, farthest and closest viewing distance and production cost. Generally, the whole screen pixel of an LED display should be more than 50,000, so that the display effect will be better. It is not recommended to use large-pitch specifications for small-area screens, but it doesn't matter if small-pitch specifications are used for large-area screens. For example, a display screen of about 8 square meters, it is recommended to choose P4 or P5, if you want to be more affordable, you can choose P6, and it is not appropriate to choose P7.62 or P8; 50 square meters of more than the display screen, you can choose P4, P5, P6, P7.62, if the production cost is enough, the display effect of P5 is of course very clear, and the choice of P6 or more is more economical. The larger the dot spacing, the farther the optimal viewing distance will be.

Here are some of the commonly used specifications for indoor full-color LED displays:

Common specification 1: P4 specification LED display pixel density is 62500 points/square meter. The standard module size is 256mm*128mm display, and the standard size of the screen box is 512mm*512mm or 768mm*768mm. Needless to say, its high definition, but its production cost is high. It is recommended that the production area of the display screen should be more than 3 square meters. The most suitable viewing distance is between 4 and 47 meters.

Common specification 2: The physical pixel density of P5 LED display is 40,000 points/square meter, the standard size of the module is 160mm*160mm, 320mm*160mm, and the standard size of the display box is 480mm*480mm or 640mm*640mm. The most suitable viewing distance of P5 color LED display is more than 5 meters, and our company's P5 color display adopts 1/16 constant current dynamic scanning mode, and the brightness can reach more than 1800cd/m2, which is enough to meet the needs of indoor brightness display and clear display. The most suitable viewing distance is 5-50 meters. At present, the outdoor full-color screen has the strongest comprehensive strength in terms of protection performance and high-definition high-brightness, and it is also the most popular indoor high-definition LED display for the majority of users. The production area of the screen is more than 8 square meters.

Common specification 3: The physical pixel density of P6 LED display is 27777 points/square meter, the standard size of the module is 192mm*192mm, and the standard size of the display box is 576mm*576mm. As the most commonly used LED electronic display in indoor full-color display. The most suitable viewing distance for P6 indoor electronic screen is more than 6 meters, and the most suitable viewing distance is 5-52 meters. The production area of the screen is more than 10 square meters.

3. After determining the size and model, combined with the customer's personalized requirements, an overall quotation plan can be basically given.

4. LED display control system: Generally speaking, there are two main brands of indoor full-color LED display control system, one is Xi'an Nova, and the other is Shenzhen Lingxingyu.

5. The supporting equipment mainly includes: 1 desktop computer with independent graphics card, video processor, lightning arrester, audio, power amplifier, power distribution cabinet and air conditioner, etc., some products in the actual project are optional and not necessary.

6. Finally, the material and installation of the steel structure: Generally speaking, there are two main installation methods for outdoor LED displays, one is installed on the wall, and the other is column installation. There is also a slight difference in the price and construction of the two.

VI、What are the important factors that need to be paid attention to when installing LED displays:

Engineers who install LED displays must master very good technology, and under normal circumstances, they must master the following important points in order to give customers a satisfactory effect.

1. It is more important to explore this in the early stage, and to design the screen according to the on-site construction situation, the reasonable combination of the installation site and the screen is an important step in the LED display installation process.

2. For the installation of LED display body, customers may understand the construction of steel structure, and generally do not know too much about the wiring and splicing of LED displays, so there must be professional engineers to guide, and the final screen operator of the other party needs to participate in order to learn more about the screen;

3. Steel frame design, generally within 3-5 days after signing the contract, the LED electronic display installation engineer will design the steel frame structure according to the actual situation of the site and the actual situation of the LED display and hand it over to the construction party.

4. Technical training of LED display: In the process of screen production, customers can send people to LED display manufacturers to learn LED display operation and simple spare parts replacement technology.

5. Calculation of screen power and power distribution facilities, in the early stage of installation, the screen must be planned in the early stage of electricity consumption and the size of the distribution cabinet, and the manufacturer of the LED display screen calculates the actual electricity consumption according to the actual situation of the screen, and cooperates with the construction party.
